  • QHW-1744
    Intel 6/7/8/9代Core i3/i5/i7處理器, Q170芯片, 4*Intel千兆網(wǎng)口, 8*USB 3.0, 4*COM
#





產(chǎn)品簡介
  • 支持Intel 6/7/8/9代Core i3/i5/i7處理器
  • 可選Intel Q170/ H110芯片
  • 4*Intel千兆網(wǎng)口, 8*USB 3.0, 4*COM
  • 2*SATA 3.0, 1*mSATA, 1*Mini-PCIe, 1*M.2
  • 1*HDMI, 1*DVI-D, 支持雙屏異顯

規(guī)格
General
CPU
 		Intel? 6/7/8/9th Gen CoreTM i3/i5/i7, Pentium?, Celeron? CPU, LGA1151
Chipset
 		Intel? Q170/ H110, TDP 6W
Memory
 		DDR4-2133/2400, 2*SO-DIMM, up to 32 GB
Storage
 		2*SATA 3.0, 1*mSATA
Expansion Interface
 		1*Mini-PCIe (PCIe+USB 2.0)
1*M.2 (Key-E, 2230, PCIe+USB 2.0)
BIOS
 		AMI UEFI BIOS
System
 		Windows 7/8.1/10, Linux
I/O Interface
Ethernet
 		3*Intel? 1Gbps Ethernet Controller, RJ45
1*Intel? 1Gbps Ethernet PHY, Support iAMT
Serial
 		2*RS232, 2*RS232/RS485/RS422
USB
 		Q170: 8*USB 3.0, 2*USB 2.0
H110: 4*USB 3.0, 4*USB 2.0
Audio
 		Realtek? Codec, with MIC + Line-out
GPIO
 		8*Programmable GPIO
Display
Display Interface
 		1*HDMI: max resolution up to 4096*2160@30Hz
1*DVI-D: max resolution up to 1920*1080@60Hz
Multiple Display
 		Dual
Mechanical & Environment
Dimension
 		203*146mm
Power Input
 		DC 12~24V
Temperature Operation: 0℃~60℃, Storage: -25℃~75℃
Relative Humidity
 		Operation: 10%~90%, Storage: 5%~95%, non-condensing
