  • QHW-Q3752A
    Intel 10代Core i3/i5/i7/i9處理器, H420E芯片, 3*PCIe slot, 4*PCI, 6*COM, 10*USB, 2*LAN
#




產(chǎn)品簡(jiǎn)介
  • 支持Intel Coffee Lake 8/9代Core i3/i5/i7/i9全系列處理器
  • 采用Intel Q370芯片組
  • 6*COM, 13*USB, 2*Intel千兆網(wǎng)口
  • 1*VGA, 1*HDMI, 1*DVI, 1*eDP, 支持三屏異顯
  • 2*PCIe x16, 3*PCIe x4, 2*PCI, 1*Mini-PCIe, 1*M.2
  • 支持vPro, AMT, RAID, TPM 2.0

規(guī)格
General
CPU

Intel? 8th and 9th Generation CoreTM i3/i5/i7/i9, Pentium?, Celeron?  CPU, LGA1151

Chipset
 		Intel? Q370 Chipset, TDP 6W
Memory
 		DDR4-2400/2666, 4*U-DIMM, up to 64 GB
Storage

4*SATA 3.0

1*M.2 (Key-M, 2242/2280, PCIe x4 NVMe/ SATA SSD)

Expansion Interface

2*PCIe x16 Slot (1*PCIe x16 Gen3 or 2*PCIe x8 Gen3)
3*PCIe x4 Slot (PCIe x4 Gen3)
2*PCI

1*Mini-PCIe (Wifi/3G/4G Supported)

BIOS
 		AMI UEFI BIOS
System
 		Windows10, Linux
I/O Interface
Ethernet

1*Intel? Ethernet Controller I219V, RJ45

1*Intel? Ethernet Controller I225V, RJ45

Serial
 		4*RS232,1*RS232/RS485/RS422, 1*RS232/RS485
USB
 6*USB 3.0, 7*USB 2.0
Audio
 		Realtek? ALC897 5.1 channel HDA Codec, with MIC/Line-out/Line-in
PS/2
 		1*PS/2 Port (Keyboard & Mouse)
GPIO
 		8*Programmable GPIO
Display
Display Interface

1*DVI-D: max resolution up to 1920*1200@60Hz

1*HDMI 1.4b: max resolution up to 4096*2160@24Hz

1*VGA: max resolution up to 1920*1200@60Hz

1*eDP: max resolutionup to 1920*1200@60Hz
Multiple Display
 		Triple
Mechanical & Environment
Dimension
 		305*244mm
Power Input
 		ATX PSU
Temperature Operation: 0℃~60℃, Storage: -25℃~75℃
Relative Humidity
 		Operation: 10%~90%, Storage: 5%~95%, non-condensing
