  • QHW-H3C34
    Intel 6/7/8/9代Core i3/i5/i7處理器, H310C芯片, 3*PCIe, 4*PCI, 6*COM, 9*USB, 2*LAN
#




產品簡介
  • 支持Intel 6/7/8/9代Core i3/i5/i7處理器
  • 采用Intel H310C芯片組
  • 6*COM, 9*USB, 2*Intel千兆網口
  • 1*VGA, 1*HDMI, 1*DVI, 1*eDP, 支持雙屏異顯
  • 1*PCIe x16, 1*PCIe x4, 1*PCIe x1, 4*PCI
  • 2*Mini-PCIe支持mSATA和Wifi/3G/4G

規格
General
CPU
 		Intel? 6/7/8/9th Generation CoreTM i3/i5/i7, Pentium?, Celeron? CPU, LGA1151
Chipset
 		Intel? H310C Chipset, TDP 6W
Memory
 		DDR4-2400, 2*U-DIMM, up to 32 GB
Storage
 		4*SATA 3.0, 1*mSATA
Expansion Interface

1*PCIe x16, 1*PCIe x4, 1*PCIe x1, 4*PCI,

2*Mini-PCIe (1*mSATA, 1*Wifi/3G/4G supported)
BIOS
 		AMI UEFI BIOS
System
 		Windows 7/8.1/10, Linux
I/O Interface
Ethernet
 		2*Intel? 1Gbps PCIe Ethernet Controller, RJ45
Serial
 		4*RS232, 2*RS232/RS485
USB
 4*USB 3.0, 5*USB 2.0
Audio
 		Realtek? ALC897 5.1 channel HDA Codec, with MIC/Line-out/Line-in
PS/2
 		1*PS/2 Port (Keyboard & Mouse)
Parallel
 		1*LPT Header
GPIO
 		8*Programmable GPIO
Display
Display Interface

1*VGA: max resolution up to 1920*1200@60Hz
1*HDMI: max resolution up to 4096*2160@24Hz
1*DVI-D: max resolution up to 1920*1200@60Hz

1*eDP: max resolution up to 1920*1200@60Hz

Multiple Display
 		Dual
Mechanical & Environment
Dimension
 		305*217mm
Power Input
 		ATX PSU
Temperature Operation: 0℃~60℃, Storage: -25℃~75℃
Relative Humidity
 		Operation: 10%~90%, Storage: 5%~95%, non-condensing
