  • QHW-B15B4
    Intel 6/7代Core i3/i5/i7處理器, B150芯片, 25*SATA, 3*LAN, 12*USB, 1*PCIe x16, 1*PCIe x4
#




產品簡介
  • 支持Intel 6/7代Core i3/i5/i7處理器
  • 采用Intel B150芯片組
  • 6*Mini-SAS (24*SATA), 1*SATA 3.0, 1*mSATA
  • 3*Intel千兆網口, 1*PCIe x16, 1*PCIe x4, 1*Mini-PCIe
  • 1*VGA, 3*HDMI, 支持三屏異顯

規格
General
CPU
 		Intel? Xeon?, 6th and 7th Generation CoreTM i3/i5/i7, Pentium?, Celeron? CPU, LGA1151
Chipset
 		Intel? B150 Chipset, TDP 6W
Memory
 		DDR4-1866/2133, 4*U-DIMM, up to 64 GB
Storage
 		6*Mini-SAS (24*SATA), 1*SATA 3.0, 1*mSATA
Expansion Interface

1*PCIe x16, 1*PCIe x4,

1*Mini-PCIe (mSATA/3G/4G supported)

BIOS
 		AMI UEFI BIOS
System
 		Windows 7/8.1/10, Server 2008/2012, Linux
I/O Interface
Ethernet
 		3*Intel? 1Gbps PCIe Ethernet Controller, RJ45
Serial
 		1*RS232, 1*RS232/RS485
USB
 4*USB 3.0, 8*USB 2.0
Audio
 		Realtek? ALC662 5.1 channel HDA Codec, with MIC/Line-out
PS/2
 		1*PS/2 Header (Keyboard & Mouse)
GPIO
 		8*Programmable GPIO
Display
Display Interface

1*VGA: max resolution up to 1920*1200@60Hz
3*HDMI: max resolution up to 4096*2160@24Hz

Multiple Display
 		Triple
Mechanical & Environment
Dimension
 		305*244mm
Power Input
 		ATX PSU
Temperature Operation: 0℃~60℃, Storage: -25℃~75℃
Relative Humidity
 		Operation: 10%~90%, Storage: 5%~95%, non-condensing
